Applications
Designed for applications to seal and protect electrical and communication connections.Provides excellent mechanical protection to cable joints and terminations, flexible gaspipes, etc....
Features
High resistance to impact, abrasion, corrosion, UV and chemical. Rated for 1 kV, 90 °C continuous use. DH-WA is recommended for applications on light cables and wire harnesses which require waterproofing, protection of connector components, and thus encapsulates and seal components contained within the tubing.
Various
Operating temperature: -55°C to +110°C
Shrink temperature: 120°C
Resistant to UV-radiation.
Standard colors: Black. Special color: Red.
Packaging:Length as standards.

Technical Data

Property	Test Method	Typical Data
Tensile  strength	ASTM D 2671	≥14MPa
Tensile strength after aging(158°C/168 hrs.)	ASTM D 2671	≥12 MPa
Elongation  at  break	ASTM D 2671	≥400%
Elongation at break after aging(158°C/168 hrs.)	ASTM D 2671	≥300%
Longitudinal   shrinkage	UL224	0 to -10%
Density	ASTM D 792	1.05g/cm3
Dielectric strength	IEC 243	≥20 kV/mm
Volume resistance	IEC 93	≥1014Ω.cm
Eccentricity	ASTM D 2671	<30%
Copper stability	ASTM D 2671	Pass
Resistance to stress cracking	ASTM D 1693(50°C)	No Cracking
Water  absorption	ISO 62(23°C/14 days)	<0.15%
Thermoplastic  adhesive  for  DH-WA
Water absorption	ISO 62	<0.2%
Softening  point	ASTM D E28	85℃
Peel  strength  (PE)	DIN 30672	4N/cm
Copper  stability	ASTM D 2671	Non-corrosive
Resistance  to fungus and  decay	ISO 846	Pass

Dimensions

Size	As Supplied(mm)	After Recovery (mm)		Standard length m
D-HW/DH-WA (D)	Inside Diameter Min. (D)	Inside Diameter Max. (d)	Wall Thickness Nominal. (t)
9/3	9	3	2.0	1.22
12/4	12	4	2.4	1.22
16/5	16	5	2.7	1.22
19/6	19	6	3.2	1.22
22/6	22	6	3.2	1.22
25/8	25	8	3.2	1.22
33/8	33	8	3.2	1.22
40/12	40	12	4.0	1.22
45/13	45	13	4.0	1.22
55/16	55	16	4.0	1.22
65/19	65	19	4.0	1.22
75/22	75	22	4.0	1.22
85/25	85	25	4.3	1.22
95/25	95	25	4.3	1.22
100/30	100	30	4.3	1.22
115/34	115	34	4.3	1.22
130/36	130	36	4.3	1.22
140/42	140	42	4.3	1.22
160/50	160	50	4.3	1.22
175/58	175	58	4.3	1.22
200/65	200	65	4.3	1.22

*Length as standards. 1 m. or 1,22 m. sticks, special lengths or cut pieces available on request.
